0.9mm E2000 Fiber Pigtail Patch Cord With LSZH Yellow Jacket

LSZH Yellow Jacket 0.9mm E2000 Fiber Pigtail For CATV/FTTH/LAN/WAN Networks

Fiber Pigtail is utilized to achieve accurate mounting for precision alignment of fiber optical components. Fiber optic pigtails provide a fast way to link communication devices, mostly used to terminate fiber optic cable by fusion or mechanical splicing. And the pigtails are usually found in ODF, fiber distribution boxes and terminal boxes, etc. They are widely used in CATV, FTTH/FTTX, LAN/WAN networks, and more.

1. Product Description of LSZH Yellow Jacket 0.9mm E2000 Fiber Pigtail For CATV/FTTH/LAN/WAN Networks:

E2000 pigtail is a cable with a high-grade E2000 fiber optic connector on one end, the end unterminated. They can configure single mode and multimode fiber for the specific application. These E2000 pigtail Assemblies are available in UPC and APC polish with simplex or duplex fiber cable versions. Cable length, cable diameter, and jacket are optional. The typical type of fiber pigtail uses 0.9mm cable because it is especially suitable for high-density splice applications.

2. Product Features of LSZH Yellow Jacket 0.9mm E2000 Fiber Pigtail For CATV/FTTH/LAN/WAN Network:

1. E2000 plug according to IEC 61754-15.
2. Single mode fiber OS2, E9/125 µm, bend insensitive according to IEC 60793-2-50 type B6_a and G.657.A1 compatible to G.652.D.
3. Compact loose tube fiber with dia. 0.9 mm, length 2.0 m.
4. Color sequence in sets according to IEC 60304: red, green, blue, yellow, white, gray, brown, violet, turquoise, black, orange, and pink. Secondary and primary coating same color.
5. Plug connector mounted on one side
6. With the test report, insertion loss and return loss were tested at 100 %
7. all available variants can be created with the cable configurator

3. Applications of LSZH Yellow Jacket 0.9mm E2000 Fiber Pigtail For CATV/FTTH/LAN/WAN Network:

1. Data Transmission Networks
2. Image transmission Networks
3. CATV
4. Optical test instrument
5. Photoelectric automatic control system

4. Technical Specifications of LSZH Yellow Jacket 0.9mm E2000 Fiber Pigtail For CATV/FTTH/LAN/WAN Network:

► The Connector

☝E2000 Connector ☝0.9mm Optical Cable

► Optical Cable
